Description

Heavy duty steel construction! Suitable for cleaning snow or pushing sand, dirt, gravel, etc. Model specific mounting kit needed for installing the push tubes (see section front-mount adapters). 34.4100 kit consist of part numbers: 34.3500 (1500 V-Plow blade) and 34.3400 (quick attach front mount push tubes for G2 V-Plow 1500 kits).

Technical Details

Working width (track) in max tuned reversed V position: 1350 mmWorking width (track) in max turned V position: 1380 mmWorking width (track) straight position: 1500 mmDifferent working angle positions.Impact reducing springs helps the plow move over small obstacles without breaking.Working height adjustment.Blade angle adjustment.Plow lifting with ATV winch.Curved design provides better snow and dirt roll-off at any angle.Packed into 2 packing units: 1210 x 800 x 340 mm wooden box + 880 x 500 x 310 mm carton box
